7.9 AutomaticFillingScaleType Definition
7.9.1 Overview
The AutomaticFillingScaleType defines the structure of an Object of the AutomaticFillingScaleType. Figure 21 shows the hierarchical structure and details of the composition. It is formally defined in Table 42.
An Object of AutomaticFillingScaleType represents an automatic filling scale. It defines additional Methods and Properties required for managing automatic filling scales.
7.9.2 ObjectType Definition
| Attribute | Value | ||||
| BrowseName | AutomaticFillingScaleType | ||||
| IsAbstract | False | ||||
| References | NodeClass | BrowseName | DataType | TypeDefinition | ModellingRule |
|---|---|---|---|---|---|
| Subtype of the ScaleDeviceType | |||||
| 0:HasComponent | Variable | Deviation | 0:Number | 0:AnalogUnitType | Optional |
| 0:HasProperty | Variable | ToleranceState | ToleranceState | 0:PropertyType | Optional |
| Conformance Units | |||||
|---|---|---|---|---|---|
| Scales AutomaticFillingScale |
7.9.3 ObjectType Description
Deviation defines the relative amount of over (positive value) or under (negative value) dosed value in relation to the TargetWeight.
ToleranceState describes the state of the tolerance deviation. Under: underneath the lower tolerance value. Over: above the upper tolerance value. In: within the tolerance values. The options “under” and “over” need to be determined via the TargetItemType information of TargetWeight.
ProductionPreset, which is inherited from ScaleDeviceType shall have instances of AutomaticFillingProductType or a subtype in the Products folder.
