7.32 RecipeManagementType Definition

7.32.1 Overview

The RecipeManagementType defines the structure of an Object of the RecipeManagementType. Figure 43 shows the hierarchical structure and details of the composition. It is formally defined in Table 95.

An Object of the RecipeManagementType contains methods and properties required for managing recipes. The description and the structure of the recipe can be found in Annex B.

7.32.2 ObjectType Definition

7.32.3 ObjectType Description

Recipe_No defines an instance of a recipe with the value “No”.

7.32.4 Method AddRecipe

Method to add an additional recipe of the RecipeType. The signature of this Method is specified below. Table 96 and Table 97 specify the Arguments and AddressSpace representation, respectively.

Signature

	AddRecipe(
	[in]	0:String		RecipeId
	[in]	0:LocalizedText		RecipeName
	[out]	NodeId		RecipeNodeId);

7.32.5 Method RemoveRecipe

Method to remove a recipe of the RecipeType. The signature of this Method is specified below. Table 98 and Table 99 specify the Arguments and AddressSpace representation, respectively.

Signature

	RemoveRecipe(
	[in]	0:String			RecipeId
	);
