7.2.2 NETCONF

A UAFX Station supporting remote management shall support a Network Configuration Protocol (NETCONF) server as defined in IETF RFC 7589 (NETCONF over TLS).

A single management entity controls all components of a UAFX Station. Figure 16 shows a UAFX Station comprised of two End Station Components and one Bridge Component, all controlled by a single management entity.

Figure 16 – Example of a UAFX Station supporting NETCONF

NETCONF messages are recommended to be transmitted using priority information defined for Remote Management in Table 1.
